The Effect of Artificial Age Time on Crystal size, Dislocation Density, Hardness and Micro Structure Rn Al 6061 Materials Alloy

Budiarto, Budiarto and Susilo, Susilo and Sanjaya, Ulung (2021) The Effect of Artificial Age Time on Crystal size, Dislocation Density, Hardness and Micro Structure Rn Al 6061 Materials Alloy. AIP Conference Proceedings, 2342 (1). ISSN 978 0 7354 4085 2

[img] Text
TheEffectofArtificialAgeTimeonCrystal.pdf

Download (656kB)
Official URL: https://aip.scitation.org/

Abstract

Research on the effect of T6 heat treatment and artificial life time on crystal size, density dislocation, hardness, and microstructure of Al 6061 alloy material made from powder metallurgy. The T6 heat treatment starts with a solid solution which is heated at 530 ° C, held for 60 minutes, then quenching into the water media, and the artificial aging process at 200 ° C and variations in the holding time of 1h, 24h, and 30h. Crystal size, dislocation density and lattice microstructure testing using X-ray diffractometer, hardness testing with Vickers scale and surface microstructure with SEM-EDX. Test results of crystal size, dislocation density, and micro lattice strain on 4 phase α-Al at the miller index plane (111), (200), (220), and (311) show that the crystal size increases with the duration of heating time of artificial aging. While dislocation density and micro lattice strain increase over a heating period of 1h to 30h, dislocation density and lattice strain decrease at the Miller index plane (111) to (311). The hardness testing of Al 6061 as-cast material was 54 HV after quenching the water hardness value of 75 HV, but after artificial aging the hardness decreased with a longer holding time from 45.50 HV to 39.95 HV. Microstructure observations with SEM-EDX, showed that the Al 6061 test sample without heat treatment showed a dominant α-Al matrix, whereas in the Al 6061 sample after the T6 process it was seen that the Mg2Si phase functioned to harden the Al 6061 alloy.

Item Type: Article
Subjects: TECHNOLOGY
Depositing User: Mr Alexander Jeremia
Date Deposited: 25 Aug 2021 06:41
Last Modified: 25 Aug 2021 06:41
URI: http://repository.uki.ac.id/id/eprint/4917
